Wheelchair Ramp Star Minibus Transport Tourist Bus All Metal Type Semi - Integral Body

MUDAN AUTOMOIBLE SHARES COMPANY LIMITED
Contact Now

Wheelchair Ramp Star Minibus Transport Tourist Bus All Metal Type Semi - Integral Body

  • 1
  • 2
  • 3

Brand Name : MUDAN

Model Number : X7 (MD6786)

Certification : ISO9001,CCC

Place of Origin : Zhangjiagang,China

MOQ : I UNIT

Price : negotiation

Payment Terms : T/T

Supply Ability : 10000 UNITS PER YEAR

Delivery Time : 35 WORKING DAYS

Packaging Details : BULK OR CONTAINER

Product Name : Mini bus

Model/ Type : Star

Length : 7.6M

Engine type : Diesel

Seats capacity : 30 pcs

Gearbox : Manual

Emission Level : Euro 3/4/5

Displacement (cc) : 2982

Max. power (hp/rpm) : 115/3200 (85kw/3,200rpm)

Max. torque (Nm/rpm) : 300/1600~2400

Engine brand : Yuchai/ISUZU/CUMMINS

Contact Now

Wheelchair Ramp Star Minibus Transport Tourist Bus New Air Condition 19 seats



Quick Details:



1:   Left hand drive

2:   Star  type

3:  10~19 seats capacity

4:   2982cc YC4FA115-20  engine

5:   All metal type, semi-integral body

6:   Air brake



Description:



In August 2005 ,it was identified in Jiangsu Province Economic and Trade Commission as "provincial-level technology center." There is 126 professional and technical person and 32 senior technical staff. Most of them are hired of the Ministry of Construction Committee of the provinces and city vehicles associations as expert members.



All vehicles are treated with cathode electrophresis,which highly imporved the vehicle corrosion resistance.



Specification:



Model

MD6768

 Overall Dimension

 Length (mm)

7,600

 Width (mm)

2,260

 Height (mm)

2,830

 Wheel base (mm)

4,100

 Vehicle Weight

 Curb (kg)

5,500

 Gross (kg)

7,600

 Seating capacity (person)

Pcs

30

 Fuel tank (L)

85

 Tires

 Quantity

6+1

 Size

215/75R17.5

 Engine

 Model

YC4FA130-30

 Emission Level

Euro 3

 Manufacturer

YUCHAI

 Displacement (cc)

2982

 Max. power (kw/rpm)

85kw/3200

 Max. torque (Nm/rpm)

300/1600~2400

 Gearbox

 JAC LC5T35

 Brake

 Air brake

 Body Structure

 All metal type, semi-integral body



Standard Configuration:

1. Laminated front windshield & tempered rear windshield

2. Aluminum sliding side window & metal bracket rear view mirror

3. One driver door, one manual folding passenger door

4. Sunroof

5. Normal seat,2+1 layout, adjustable driver seats(back is adjustable)

6. PVC floor

7. MP3 player, 2 speakers

8. Defrosting system for front windshield

9. Rear luggage box

10.Normal interior



Application:



1: Public transportation;

2: Tourism mini bus;

3: City bus;

4: School bus
